Place of Origin: | Hunan, China (Mainland) |
---|---|
Brand Name: | SHILI |
Model Number: | SLMP20 |
Particle Shape: | Sharp |
Grading System: | ISO |
Available Size: | (0-0.25)-(40-60) |
Application: | Lapping / Polishing |
Type: | Micron |
Color: | Yellow |
Metal Coated: | None |
Min. Unit of Measure: | Carats |
---|---|
Min. Order Quantity: | 1000 |
Delivery Time: | 7 days once getting P/O |
Packaging Details: | in plastic bags/bottles , then to cartons. |
OEM: | Yes |
Payment Terms: | T/T |
Superhard material diamond Micron grit
Shili superhard material supplies diamond micro powder. They are kinds of milled crystals through crush the synthesized crystals. The high precision standards and narrow size distribution let the diamond powder have the excellent results in grinding, lapping and polishing of ultra hard materials and hard brittle materials.
|
Grade |
Description |
Application |
|
SLMP10 |
Use SLRVD-A as raw material, Main for resin bond Superior friable shape Aggressive crystal ideal for high efficiency field |
Cemented carbides Special steels Glass, Ceramics, nature stones Hard metal dies and hard material Honing of CI cylinders |
SLMP20 |
Use SLRVD-B as raw material, Main for metal bond Superior toughness and impact strength
|
Cemented carbides Special steels Glass, Ceramics, nature stone Hard metal dies and hard material Honing of CI cylinders |
Size(μm) |
Mesh size |
D50(μm) |
SLMP10 |
SLMP20 |
0-0.25 |
#60000 |
0.11~0.20 |
* |
* |
0-0.5 |
#30000 |
0.2~0.3 |
* |
* |
0-1 |
#20000 |
0.5~0.6 |
* |
* |
0-2 |
#13000 |
0.8~1.0 |
* |
* |
1-2 |
#12000 |
1.1~1.3 |
* |
* |
1-3 |
#10000 |
1.6~1.7 |
* |
* |
2-4 |
#6000 |
2.6~3.0 |
* |
* |
3-5 |
#4000 |
3.5~4.2 |
* |
* |
4-8 |
#3000 |
5.0~6.0 |
* |
* |
5-10 |
#2000 |
6.5~7.3 |
* |
* |
7-10 |
#1800 |
7.3~8.3 |
* |
* |
6-12 |
#1600 |
8.3~9.0 |
* |
* |
7-14 |
#1500 |
9.1~10.5 |
* |
* |
8-16 |
#1300 |
10.0~12.0 |
* |
* |
10-20 |
#1200 |
12.5~15.0 |
* |
* |
12-22 |
#1000 |
15.0~17.0 |
* |
* |
15-25 |
#800 |
18.0~20.0 |
* |
* |
20-30 |
#700 |
20.0~23.0 |
* |
* |
22-36 |
#600 |
23.0~26.0 |
* |
* |
20-40 |
#500 |
26.0~29.0 |
* |
* |
30-40 |
#400 |
32.0~36.0 |
* |
* |
36-54 |
#350 |
37.0~43.0 |
* |
* |
40-60 |
#300 |
44.0~51.0 |
* |
*
|
Coated diamond powder
For SLMP series,Shili superhard material offers Nickel Coating diamond powder. By improving the particle retention to protect the diamond and extend the lifetime of tools,and improving heat dissipation capacity for cost efficacy of diamonds.
Customized for your particular requirements
Shili superhard material provides high quality synthetic diamond powder and micron powder for more than 800 customers home and abroad,meet their requirement for high performance. Besides,we provides also highly professional technical guidance,all our powder can be customized to meet customers' special requirement in application of diamond tools.
